Product Details:
Payment & Shipping Terms:
|
| Working Area : | 1300×2500mm | Laser Power : | 60W / 80W / 100W / 120W / 150W |
|---|---|---|---|
| Engraving Speed: | 1-60000mm/min | Cutting Speed : | 1-10000mm/min |
| Repeat Location Accuracy : | ± 0.0125mm | Controlling Mode: | CNC Professional Control System |
| Control Software : | Original Perfect Laser Engraving & Cutting Software | Voltage : | 220V(±10%) 50Hz |
| High Light: | co2 laser cutting system,co2 laser engraving cutting machine |
||
60W / 80W / 100W CO2 Laser Engraving Machine , Small cnc laser cutter With Stable Laser Beam
★ Product Introduction:
The machine is designed for delicate fabric cutting, its precision could reach 0.1mm, the cutting chinks are slight without scorched or brown edges. Besides, with its low consumption, the machine not only doesn't need to change tools frequently, but also doesn't need to consume the film.
★ Features:
1.High speed laser cutting machine adopts the new high efficiency laser tube,the laser beam is
more stable than the traditional type,and the life time of the laser tube is very long .
2.Compared with the ordinary laser machine,the series adopts more scientific design and high
strength steel frame structure,which increase the fuselage strength more than 40% to prevent the machine from dsitortion during long term work.
3.The humanized and mordem appearance shows Machinery consistent humanity idea,
and it also makes the operation and maintenace quite easy.
4.Advanced Ruida control system,professional motion control chip,consecutive high speed
curve cutting and the shortest path selection function improve the working efficiency a lot.
★ Application:
1. Applicable materials: Non-metal materials such as acryl, wood planks, organic glass, plastic, light planks, bamboo ware, double color sheets, cloth, paper, leather, shells, ox horns, resin, animal grease, ABS boards, lamp shade, etc.
2. Applicable Industries: For advertising, wood-working, plastic products, handicrafts, leather processing, paper cutting, etc.
★ Technical Parameters:
| Model | PEDK-130250 |
| Working Area | 1300×2500mm |
| Laser Power | 60W / 80W / 100W / 120W / 150W |
| Laser Type | Hermetic and Detached Co2 Laser Tube |
| Engraving Speed | 1-60000mm/min |
| Cutting Speed | 1-10000mm/min |
| Repeat Location Accuracy | ± 0.0125mm |
| Laser Power Controlling | 1-100% Manual Adjustment and Software Controlling |
| Voltage | 220V(±10%) 50Hz |
| Cooling Mode | Water Cooling and Protect System |
| Cutting Platform | Professional Thickening Strip or Honeycomb Work Table |
| Controlling Mode | CNC Professional Control System |
| Support Graphics Formats | BMP, HPGL, JPEG, GIF, TIFF, PCX, TAG, CDR, DWG, DXF Compatible HPG Order To Support DXF, WMF, BMP, DXT |
| Power Controlling Mode | Laser Energy Combining Movement Control System |
| Control Software | Original Perfect Laser Engraving & Cutting Software |
★ Machine Parts:
1. Prompt deliver at the very day.
2. Well-trained and disciplined packing team.
3. After-sale service:. Any questions or problems after receiving the product, please feel free to contact us. Problems would be solved for you immediately.
4. Sophisticated and professional logistic agent.
