Product Details:
Payment & Shipping Terms:
|
| Color: | Blue & White/ Red & Black | Water Chiller Model: | CW-3000,5000 5200 |
|---|---|---|---|
| Laser Power: | 60w,80w,100w,120w,150w | Software: | Perfect Laser Professional Cut Software |
| Engraving Speed: | 1-70000 Mm/min | Cutting Speed: | 1-10000 Mm/min |
| Voltage: | 220V(±10%) 50Hz | Cutting Platform: | Professional Thickening Strip Or Honeycomb Work Table |
| Repeat Location Accuracy: | ± 0.0125mm | Power Controlling Mode: | Laser Energy Combining Movement Control System |
| Control Software: | Original Perfect Laser Engraving & Cutting Software | ||
| High Light: | co2 laser engraver,co2 laser engraving cutting machine |
||
Multi-function CO2 Fabric Laser Engraving Machine 1300*900mm 1-10000mm/min Cutting Speed ,CNC Laser Engraver
(PEDK-13090A)
★ Product Introduction:
Co2 laser cutting machine fixed with a selective rolling & automatic feeding system, which make the whole cloth processing steps finish in one time. Suitable for engraving and cutting on very long work piece, such as one roller of cloth, fabric, leather, garment, carpet.
This laser fabric cutting machine especially applied in Fabric and Garments and Carpet Industry.
★Product Features:
1. Install " automatic feeding and rolling system: to make the whole cloth process steps finish one time, suitable for engraving /cutting on very long work piece, such as one roller of cloth/fabric/leather/paper etc.
2. Matched software of laser fabric cutting machine is particularly designed and written for engraving and cutting ,with high compatibility, support any computer operating system, also can according to your requirement to set the engraving length of material.
3. The laser fabric cutting machine adopts thickness crawler type working table, which can push material and keep them as planar/even/flat surface during working.
4. The laser caving machine adopt advanced LCD touching screen, with USB port and DSP offline control system, which make the The laser fabric cutting machine can not only work without computer, but also connect to U disk, USB communication.
5. Red Light Pointer realizes the exact position without laser.
★ Application and Samples:
1. The laser fabric cutting machine’s widely used in clothing material: leather engraving and cutting, textile engraving, fabric engraving, cloth engraving, shoe engraving, jeans engraving, carpet engraving and cutting, toy cutting, woolen cutting, denim engraving and cutting.
2. Advertisement material, includes acrylic, plastic, PVC board, rubber plate, seal, organic glass, plexiglass engraving, paper engraving and cutting.
3. Wood material: wood engraving and cutting, MDF engraving, plywood cutting.
★ Technical Parameters:
| Model | PEDK-13090A |
| Working Area | 1300×900mm |
| Laser Power | 60W / 80W / 100W / 120W / 150W |
| Laser Type | Hermetic and Detached Co2 Laser Tube |
| Engraving Speed | 1-60000mm/min |
| Cutting Speed | 1-10000mm/min |
| Repeat Location Accuracy | ± 0.0125mm |
| Laser Power Controlling | 1-100% Manual Adjustment and Software Controlling |
| Voltage | 220V(±10%) 50Hz |
| Cooling Mode | Water Cooling and Protect System |
| Cutting Platform | Professional Thickening Strip or Honeycomb Work Table |
| Controlling Mode | CNC Professional Control System |
| Support Graphics Formats | BMP, HPGL, JPEG, GIF, TIFF, PCX, TAG, CDR, DWG, DXF Compatible HPG Order To Support DXF, WMF, BMP, DXT |
| Power Controlling Mode | Laser Energy Combining Movement Control System |
| Control Software | Original Perfect Laser Engraving & Cutting Software |
★ Machine Parts
1. Prompt deliver at the very day.
2. Well-trained and disciplined packing team.
3. After-sale service: Any questions or problems after receiving the product, please feel free to contact us. Problems would be solved for you immediately.
4. Sophisticated and professional logistic agent.
★Competitive Advantages
1. We offer high quality products at competitive price in quick delivery.
2. 100% custom pass guaranteed.
3. Good after-sale service.
4. Flexible and Untraceable payment terms.
5. Our products have been exported to Germany, Norway, Poland, Finland, Spain, UK, France, Russia, USA, Brazil, Mexico, Australia, Japan, Korea, Thailand, Indonesia, Uruguay and many other countries.
