Owing to the patented printing technology employed by it, the handheld inkjet marker replaces obsolete handheld coding devices (such as stencil duplicators, ink roll coding devices, which are both labor-intensive and costly in use and also problematic for ink inefficiency reasons). It also can be called handheld printer,handheld inkjet marker,small portable inkjet printers,handheld inkjet marking systems,jet ink printer,inkjet industrial printers,portable inkjet coder.
Our new product is a portable, handheld, ultra compact and light handheld inkjet marker equipped with an electromagnetic valve-based print head, a battery and wireless control. This unique handheld inkjet marker weighing only 1580 grams has been developed for the users who use the freedom of marking, coding and labeling of their products at any place and at any time as the major criterion of choice. This handheld printer is also for the users who show a high demand for cost effectiveness and operating efficiency and as the same time very excessive demand for extended utility functions. The handheld printer offers all basic capabilities typical of handheld inkjet marker.
II. Product Features
1.Integrated and hand-held design.
2. Many kinds of machine crust choices
3. 4.5 inch color touch screen
4.No ink waste:
5. Any printing direction:
6. More than 30 kinds printing fonts:
7. USB interface, available to computer transfer logo trademarks and so on;
8. Exquisite packaging, fashionable outer packing for easy carrying.
9. Battery and charger for use. Battery is installed at the bottom of the printer and it can be used as printer base. Equipped with the charger for convenient charging.
1, the ink-jet printing material: metal, plastic, wood, stone, light-gauge steel, pipe materials such as aluminum foil, cardboard boxes and building materials surface
2, the application of products: mainly used in product packaging printing code, date, batch number, and so on. Widely used in food, beverage, pharmaceutical, chemical, cement and other industries. Jet Printing in permeable surfaces (such as ordinary cardboard boxes, templates, textile, etc) and non-permeable surfaces (such as bags, tubes, smooth cardboard, etc).
| Print speed | Up to 45 metres per minute, and the print speed does not change due to increase of the number of printing lines |
| Printing material | Permeable and impermeable material |
| Printing graphics | logo, graphics can be imported through a USB stick |
| Print content | All English words, numbers, bar codes and graphics |
| Automatic printing | The date, time, batch number, frequency, and serial number (may vary according to time of day change) |
| Printing accuracy | 300DPI(High-definition) |
| Printing rows | Adjustable 1-7 line printing bar codes |
| Printing distance | 2mm～5mm |
| Production serial number | 1-8-variable sequence number |
| Store information | Systems can store more than 1000 huge amounts of information (external USB flash drive to save the information) |
| Message length | over more than 2000 fonts |
| Printing fonts | More than 30 kinds frontes |
| Ink | Quick-drying ink, ink, oil ink, invisible ink |
| Ink color | Black, red, blue, yellow, green |
| Cartridge capacity | 42 ml, a box of ink jet printing of 400,000 characters (2mm) |
| Power time | 3 hour charge, available for 8 hours (when the screen saver is enabled) standby time 24 hours |
| Battery capacity | 2200 mA lithium-ion battery |
| Power voltage | DC16.8V |
| Status display | LED light flashes that work LED lights fast shiny, printing work. |
| System power consumption | Average power consumption is lower than 5W |
| Application environmental | Temperature 1 ° c ~38 ° c ; humidity 10%~80% |
| Character height | 1mm～12.7mm |
Q: What’s the package?
A: We have 3 layers package. For the outside, we adopt wood craft case. In the middle, the machine is covered by foam, to protect the machine from shaking. For the inside layer, the machine is covered by thickening plastic bag for waterproof.
Q: Will the package damaged during transportation?
A: Our package is considerate all the damage factors and make it to be safe, and our shipping agent have full experienced in safe tranportation. We have exported to 180 countries worldwide. So please don’t worry, you will receive the parcel in good condition.
Q: How to install and run the machine?
A: Our technician have installed the machine before shipping. For some small parts installation, we will send detail training video, user’s manual along with the machine. 95% customers can learn by themselves.
Q: How can I do if the machine goes wrong?
A: If confronted with such problems, please contact us asap and do not try fix the machine by yourself or someone else. We will response within 24 hours as quick as we can to solve it for you.
360 Degrees Inkjet Coding Printer DC16.8V With USB Interface , 300DPI High Resolution.pdf
