There are currently three major marking equipment in marking industry, which are thermal transfer overlays TTO, ink marking machines and laser marking machines.
Thermal transfer overlays TTO: they’re the preferred equipment of soft packing products and can mark on the soft package and flat package bag. What’s more, their resolution is up to 300dpi. they belong to contact-type marking equipment.
Ink marking machines: they belong to non-contact type ink jet marking equipment, controlled
by SCM. They’re currently the market mainstream, mainly divided into big character and small character.
Laser marking machines: they’re mainly divided into CO2, optical fiber and solid flying marking machines.
1. It uses hardware DSP chip card and can finish calculation in 1us and real-time positioning in 10us, which ensures no omission and no deformation in high-speed flight;
2. It uses LINUX kernel and its operating system is cleaner and safer, and not easy to be poisoned and suddenly interrupted;
3. The optimum graphics optimizes marking path control algorithm. When using the same laser power and galvanometer, it spends less time to mark, and make production line faster and more efficient.
4. When printing movable words in high speed, it supports double Buffer and mark without delay;
5. Under the inductive mode of external sensor, it can memorize 16 sets of trigger position, which makes the trigger switch position more flexible and it provides intelligent omission detection to prevent omissions, improving efficiency;
6. It can realize not to mark on the intersection of words and graphicss, which can effectively avoid overlap. And the words with intersections are specially dealt with, which improves the marking speed;
7. It supports ultralong text (it can edit 16-meter text and graphics and control paragraph space of marked content better);
8. The marking content is more comprehensive which includes common graphs (point, line, circle, rectangle, etc.), fixed text, movable text (serial number, date, shift, random number, txt), vector graphics (dxf, plt, dot), and bar code (one / two-dimensional code, movable text rules);
9. It can realize highspeed communication marking (RS232 communications, TCP/IP communications), and real-time alarm on omissions;
10. It provides intelligent guide set function, which greatly speeds up the installation and setting of laser marking machine on the production line;
11. It has multilevel password protection to avoid operation error;
12. It can mark under network remote control;
13. Its I/O port is open, which makes procedure marking more convenient and connection with external equipment better.
1. The marking process is automatic, high-speed and efficient. The marking effect is fabulous;
2. It uses self R&D fiber laser, which has advantages of high optical conversion efficiency, small size, low cost, no consumables and maintenance-free;
3.It bears the capability of 7*24 hours continuous working, which can meet the requirements of large-scale online continuous production;
4. It can achieve the communication without delay between the laser and the bus board. Compared with the product equipped with the same configuration, the marking speed has doubled;
5. It adopts the special scanning galvanometer system of the marking system, which can not only improve the overall stability of the product, but also guarantee the good quality in high-speed marking.
Laser online marking machines are widely used in food, beverage, alcohol, electronic components, handicrafts, chemical and industrial building materials, cables, card printing and other products. They’re used to mark expiry date, batch number, shift, bar code, manufacturer’s name and logo, etc.. They can plate coating layer on the surface of various metalloid and metal, and mark on PVC, PET, ABS, PP and PS, etc..
|
Laser type |
Fiber laser |
Maximum scanning speed |
10000mm/s |
|
Laser wavelength |
1064nm |
Cooling |
Forced air |
|
Average output power |
20W(optional) |
Supply requirements |
220V 50Hz |
|
Repetition frequency |
20kHz-60kHz |
Consumption |
≤0.5kw |
|
Line width |
0.15mm |
Environmental temperature |
-5℃-45℃ |
|
Minimum character height |
0.5mm |
Environmental humility |
10%-90% |
|
Marking range |
110mm×110mm (differing from the lens) |
Maximum speed adapting production line |
200m/min(differing from the contents and materials) |
|
Marking lines |
Random in range |
Software |
Special system |
|
Displacement accuracy |
±0.001mm |
Hand-held display terminal |
10.2 inch |
