Print height

7-58mm

Need to stick mark the height of the object

The height of 70mm - contact two drum 35mm height - only contact with the roller printing, for example, only seven nozzle. Cylindrical objects, such as printing, as well as to the catheter and barrels of spray

Spurt the code machine working position

Any location

The nozzle diameter

Standard 150 microns optional 150 microns, 170 microns to 200 microns

The maximum number of characters in each text

1300 characters (if using built-in font spurt the code machine, the control characters are included)

At the same time stored in the spurt the code machine memory text and print the number of parameter set

From 1 to 10 text through computer loading to spurt the code machine from 1 to 30 (optional)

Special font

Used for communication, warning, disposal or other USES of national character and graphic character characteristic inflexion.

Variable-length field

The device can spray print any date and time formats, including valid/service period, the increment or decrement the counter, general counter (universal counter can be used to calculate parts, pallet, number of meters, etc.).

Edit text and printing parameters, spurt the code machine control

IBM system compatible with the computer, through the radio/radio spectrum communicate with printing machine (within 50 meters distance)

Suggested that the minimum requirements

for the computer

IBM compatible computer, equivalent to pentium 200, 32 MB RAM, 20 MB of disk space available to run the control program is 1.5 or higher of EBS - 250 spurt the code machine, computer need to install any of the following operating system: Windows ® 98 se/ME/NT / 2000 / XP/Vista ® / 7 if your computer is running Windows NT ® program, only need to spurt the code machine with a RS - 232 interface connection can realize communication (not via USB) can reach 60 of the machine will summarize to the remote network by computer or radio terminal

Timing

In the process of spray print, regardless of the spurt the code machine rotational speed is fast or slow, timing can be synchronous with the roller speed, the time interval with internal can also generate synchronization.

The power supply

A full charge when running roughly time when recharge the built-in battery temperature at 20 degrees, the machine can last for 50 hours non-stop printing, insufficient battery automatic display Automatically through external dc 24 v / 1 A power pack charging charging time when she was 150 minutes (2.5 hours) charge cycle: 500 times (battery capacity is 70% of the initial capacity)

Ink

The cartridge capacity Ink can be used to bayonet fixed container can be removed. The main components of the ink juice with alcohol, and water. There are white, yellow, green, red and black are available, you can order in our directory column. 110 ml can print 7 x 5 pixels matrix of about 100000 words operator or 16 x 10 pixels matrix about 17, 000 characters.

Working temperature range

Used for water-based ink jet printing of storage temperature should be controlled between 1 to 45 degrees, the type of ink used to spray print or ethanol storage temperature should be controlled between 10 degrees to 45 degrees below zero.

Vertical size (length/width/height)

226/75 226/75/259 mm / 255 mm
