9600DPI Wall Poster Printing Machine 3D Vertical Aluminum Magnesium Alloy Body

9600DPI Wall Poster Printing Machine 3D Vertical Aluminum Magnesium Alloy Body

9600DPI Wall Poster Printing Machine 3D Vertical Aluminum Magnesium Alloy Body
9600DPI Wall Poster Printing Machine 3D Vertical Aluminum Magnesium Alloy Body
9600DPI Wall Poster Printing Machine 3D Vertical Aluminum Magnesium Alloy Body
9600DPI Wall Poster Printing Machine 3D Vertical Aluminum Magnesium Alloy Body
9600DPI Wall Poster Printing Machine 3D Vertical Aluminum Magnesium Alloy Body
9600DPI Wall Poster Printing Machine 3D Vertical Aluminum Magnesium Alloy Body
Minimum Order Quantity:
1 Unit
Price:
Negotiable
Packaging Details:
Sea-Worthy Packing Or Air-Worthy Packing
Delivery Time:
10-15 Working Days
Payment Terms:
T/T, L/C
Supply Ability:
5000 Units per year
Get Best Price
Contact Now Chat Now
Detail Information
Place of Origin:
China
Brand Name:
Perfect Laser
Certification:
CE / ISO
Model Number:
PE-S80
Product Name:
Wall Printer
Printing Head:
Japan Imported Industrial Grade Printing Head
Main-board Configuration:
6-core CPU, 2GB DDR Memory
UPS Battery Life:
About 12 Hours
Pad Size:
11.6 Inch
Rail Size(L×H):
4500mm×2500mm
Ink Consumption Per Square:
6-10ML
Nozzle Cleaning:
One Key Automatic
Painting Accuracy:
9600DPI
Language:
Chinese And English (Customizable)
High Light:
CE 3D wall poster printing machine , 9600DPI wall poster printing machine , Aluminum Magnesium 3D vertical Wall Printer
Product Description

3d Vertical Multicolor Office Wall Art Decoration Indoor And Outdoor Wall Poster Printing Machine

(Model:PE-S80)





★ Product Introduction:



Brightness a new vertical cable standard version wall poster printing machine. Made of aluminum-magnesium alloy assembly body, the chassis is thin and durable. In the product performance, the stability has been significantly improved. Higherpainting speed, simple operation, free maintenance, no need to move during work, suitable for large format painting, for beautiful picture, a wide range of applications, this machine is the wall printing prior choice.





★ Product Features:





1. Sprinkler data signal using optical fiber integrated output. Faster, anti-interference ability, high reliability, stable transmission data.



2. Automatic fill system. Construction accidentally interrupted, fill system of the wall printer can effectively reduce the painting scrap rate.



3. Fuselage reserved UPS, inverter interface (can be installed built-in power supply system, the mural printing machine power off for about 10 hours).



4. The wall poster printing machine adopts advanced AC servo control technology to ensure higher precision printing, better stability and longer service life of the mural printing machine.



5. Integrated head design of the wall poster printing machine, separable structure. Effectively avoid the damage caused by handling bumps, all around the nozzle installation board, thus extending the actual life of the printing head.



6. The wall poster printing machine is equipped with simple multi-color ink cartridges ink system, stable and convenient, to support the separation of fast lines, water and electricity separation, with the take with the release.



7. The wall poster printing machine adopts united States imported sensor system, dual sensors, up and down two-way sensor, surface tracking, automatic positioning, automatic solution to the wall uneven, wall tilt and other issues, effectively reducing the risk of head damage.



★ Application:



Applicable wall surface: white gray wall surface, blue brick wall surface, red brick wall surface, cement wall surface

Applications:

Schools, office buildings, bars, shopping malls, residences, restaurants, public halls, amusement parks and so on.



9600DPI Wall Poster Printing Machine 3D Vertical Aluminum Magnesium Alloy Body 0





★ Technical Parameters:



Model PE-S80 wall poster printing machine
Printing Head Japan imported industrial grade printing head
2 pcs
Painting Speed 64㎡/h
Main-board Configuration 8-core CPU, 4GB DDR memory
UPS Battery Life About 12 hours
Pad Size 11.6 inch
Rail Size(L×H) 4500mm×2500mm
Host Size (L×W×H) 400mm×320mm×2500mm
Sensor Double
X Axis Effective Stroke 2000mm
Y Axis Effective Stroke Unlimited
Z Axis Effective Stroke 150mm
Z Axis Guide 170mm
Z Axis Automatic Have
Ink Consumption Per Square 6-10ML
Nozzle Protective Device Have
Spirit Level Have
Automatic White Jump Have
Nozzle Cleaning One Key Automatic
Painting Accuracy 9600DPI
Painting Direction Vertical
Painted Mode two-way
Ink Tank Capacity 400ML=100ML×4
Spray Distance 0.5-2.0cm
Ink Supply Method Automatic ink supply under negative pressure
Data Transmission Method USB2.0/3.0
Certification CE/GB18582-2001/GBT9756-2001
Power Supply AC110V (90-132V)/AC220V (180-264V) , 47-63HZ
Power Consumption No load:20W, Generally:75W, MAX: 250W
Noise Standby <20dBA, Drawing <50dBA
Working Temperature -10°C-60°C (14°F-140°F) 10%-80% relative humidity, non-condensing
Storage Temperature -30°C-60°C (-22°F-140°F) 10%-80% relative humidity, non-condensing
Language Chinese and English (Customized)
Training VCD training, Engineer overseas training is available (charged additionally)
Guarantee 12 months





★ Machine parts:



9600DPI Wall Poster Printing Machine 3D Vertical Aluminum Magnesium Alloy Body 1





★ Packaging & Delivery:



1. Prompt deliver at the very day.

2. Well-trained and disciplined packing team.

3. After-sale service:. Any questions or problems after receiving the product, please feel free to contact us. Problems would be solved for you immediately.

4. Sophisticated and professional logistic agent.





★Competitive Advantages:



1. 100% custom pass guaranteed.

2. Our products have been exported to Germany, Norway, Poland, Finland, Spain, UK, France, Russia, USA, Brazil, Mexico, Australia, Japan, Korea, Thailand, Indonesia, Uruguay and many other countries.

3. Flexible and Untraceable payment terms.

4. Good after-sale service.

5. We offer high quality products at competitive price in quick delivery.
