High Speed Plasma Cutting Machine Industrial Desktop CNC Plasma Cutter CE Approval

High Speed Plasma Cutting Machine Industrial Desktop CNC Plasma Cutter CE Approval

High Speed Plasma Cutting Machine Industrial Desktop CNC Plasma Cutter CE Approval
High Speed Plasma Cutting Machine Industrial Desktop CNC Plasma Cutter CE Approval
High Speed Plasma Cutting Machine Industrial Desktop CNC Plasma Cutter CE Approval
Minimum Order Quantity:
1 Unit
Price:
Negotiable
Packaging Details:
Sea-Worthy Packing
Delivery Time:
7-15 days
Payment Terms:
T/T, L/C, PayPal, Western Union
Supply Ability:
300 Unit per Month
Get Best Price
Contact Now Chat Now
Detail Information
Place of Origin:
China
Brand Name:
Perfect Laser
Certification:
CE / ISO / FDA
Model Number:
PE-CUT-A3
Effective Cutting Width(㎜):
Track Gauge-1500
Effective Cutting Length(㎜):
Gauge Length-3000
Plasma Cutting Thickness(mm):
1-25mm
Cutting Torch Lifting Stroke(㎜):
60mm
After-sales Service Provided:
Engineers Service Overseas
Machine Running Speed(mm/min):
50-45000mm/min
Velocity Error(%):
≤±5%
Automatic Height Adjustment Accuracy(MM):
≤±1.0mm
Weight:
550KG
Vertical Line Accuracy:
±0.2mm/10m
High Light:
plasma cutting equipment , plasma cutting cnc machine
Product Description

High Speed Automatic Industrial Desktop CNC Plasma Cutter With Heavy Machine Tool Design



(Model:PE-CUT-A3)





※Introduction of Desktop CNC Plasma Cutter





Desktop CNC Plasma Cutter PE-CUT-A3 adopts heavy machine tool design , it combined with the high speed cnc plasma cutting and the need for plate processing heavy machine stability. Berefore, this best
plasma cutter has good rigidity and long stability as well as a significant advantage in thick steel and aluminum materials in cutting 1-20 mm. At the same time, the plasma cutters for saleis equipped with automatic height adjustment system, it can improve work efficiency and save costs.



High Speed Plasma Cutting Machine Industrial Desktop CNC Plasma Cutter CE Approval 0





Features of Desktop CNC Plasma Cutter





1.Maximum working area of the Desktop CNC Plasma Cutter: 1.5*3M; Cutting thickness: 5MM; The maximum cutting thickness: 25MM

2.Processing materials of the Desktop CNC Plasma Cutter: cold binding plate, stainless steel plate, galvanized sheet, copper plate, aluminum plate and other metal sheet.

3.This cnc plasma cutter is specially developed for the cutting of sheet metal, and the cutting accuracy and effect have reached the requirements of the industry.

4. This Desktop CNC Plasma Cutter can support AI, DXF, PLT, and other graphics data format;this plasma cutting table is also able to accept MasterCam, Type3, Wen Tai software generated international standard G code.

5. The CNC system of the best plasma cutter uses the current advanced integrated module control mode, which ensure that the equipment in high precision, high stability in the state of reliable operation

6. With Automatic calculation of cutting slot compensation, the plasma cutting table can greatly reduce the production time processing of data and can ensure accurate processing of graphic size.

7. The Desktop CNC Plasma Cutter with automatically optimize the order of processing, but also manual adjustment, reduce processing time, improve processing efficiency.

8. Unique breakpoint, power failure processing, the processing process of the cnc plasma cutting machine can track along, back, flexible handling process encountered arcing, power failure.

9.After the system transfers graphics and image data, the cnc plasma cutter can edit and edit such as zoom, rotate, align, copy, combine, split, smooth, merge, etc.

10.This Desktop CNC Plasma Cutter can increase the output and programming operation of the front and back table as well as the cutting function of the machining area and the border.

11.Automatic arc, automatic adjusting system, cutting steel plate with rugged automatic adjustment function, to ensure uniform distance between the cutting torch and the plate cutting, thus the cnc plasma cutter can ensure the cutting quality.



High Speed Plasma Cutting Machine Industrial Desktop CNC Plasma Cutter CE Approval 1

High Speed Plasma Cutting Machine Industrial Desktop CNC Plasma Cutter CE Approval 2

High Speed Plasma Cutting Machine Industrial Desktop CNC Plasma Cutter CE Approval 3

High Speed Plasma Cutting Machine Industrial Desktop CNC Plasma Cutter CE Approval 4

High Speed Plasma Cutting Machine Industrial Desktop CNC Plasma Cutter CE Approval 5

High Speed Plasma Cutting Machine Industrial Desktop CNC Plasma Cutter CE Approval 6



Application of Desktop CNC Plasma Cutter





Printing Material: This Desktop CNC Plasma Cutter  is widely applied in special-shaped carbon steel, manganese steel, stainless steel, non-ferrous metals (stainless steel, aluminum, copper, titanium, nickel) and other metal materials of large, medium and small plates.

Application field: This Desktop CNC Plasma Cutter is widely applied in shipbuilding industry, heavy machinery, petrochemical, power equipment, boiler manufacturing, machinery manufacturing, aerospace, vehicle manufacturing.


High Speed Plasma Cutting Machine Industrial Desktop CNC Plasma Cutter CE Approval 7



Specifications of Desktop CNC Plasma Cutter



Model PE-CUT-A3
Effective CuttingWidth(㎜) Track Gauge-1500
Effective CuttingLength(㎜) Gauge Length-3000
Plasma CuttingThickness(mm) 1-25mm
Cutting Torch LiftingStroke(㎜) 60mm
Machine RunningSpeed(mm/min) 50-45000mm/min
Velocity Error(%) ≤±5%
Automatic HeightAdjustmentAccuracy(MM) ≤±1.0mm
Weight 550KG
Vertical Line Accuracy ±0.2mm/10m
Linear Repetition Accuracy ±0.4mm/10m
InstallationAccuracy of Rail

Rail Side Straightness:0.5mm/10000mm

The parallel degree between the rail and the horizontal

plane of the guide rail:±0.5mm/10000mm

PositioningPrecision 0.1㎜

A)Equipment positioning accuracy and repeatability: conform to JB/T5102-1999 standard

B)Cutting dimension accuracy, section quality: conform to JB/T10045.3-1999 standard

Straightness 0.2㎜
Roundness 0.2㎜
DiagonalDifference 0.3㎜
RepeatedPositioningAccuracy 0.5㎜
Machine MarkingAccuracy ≤0.5mm



Cutting SurfaceQuality(Roughnes)

(σ=25)



RZ(um)=70+1.2a

Visual Measurement: roughness12.5






※Sample Show of Desktop CNC Plasma Cutter


High Speed Plasma Cutting Machine Industrial Desktop CNC Plasma Cutter CE Approval 8






Packaging & Delivery


1. Prompt deliver at the very day.
2. Sophisticated and professional logistic agent.
3. Well-trained and disciplined packing team.
4. After-sale service:. Any questions or problems after receiving the product, please feel free to contact us. Problems would be solved for you immediately.





Competitive Advantages


1. We offer high quality products at competitive price in quick delivery.
2. 100% custom pass guaranteed.
3. Good after-sale service.
4. Flexible and Untraceable payment terms.
5. Our products have been exported to Germany, Norway, Poland, Finland, Spain, UK, France, Russia, USA, Brazil, Mexico, Australia, Japan, Korea, Thailand, Indonesia, Uruguay and many other countries.
