Digital Galvanometer 3D Laser Engraving Systems Air Cooled With 1 Year Warranty
(Model:PE-DP-C)
★ Application field of 3D Laser Engraving Systems
1. Applicable materials: surface materials such as crystal, glass, acrylic, decorative materials.
2. Applicable industries: used in consumer activity industries such as tourism, hotels, photo studios, advertising, etc.
★ Product Descriptions of 3D Laser Engraving Systems
We are a professional company specializing in the development and production of laser machines. Our crystal laser engraving machine is designed for large-scale 3D laser engraving. We use large-format processing platform to greatly improve efficiency, shorten engraving time by 50%, and fully automatic batch processing program, so that the equipment is unattended, and still can continue to work.
★ Features of 3D Laser Engraving Systems
1. The device uses modular equipment, which is easy to maintain
2. Pulse laser power constant technology greatly improves the quality of laser engraving.
3. With automatic laser positioning system, no need to maintain the light path
4. Specially designed high-power semiconductor pump laser with internal laser engraving and material surface engraving function, laser collimation technology and closed control system can run continuously for 24 hours;
5. Continuous improvement of image processing technology, making realistic engraving products with unprecedented engraving effects.
★ Sample of 3D Laser Engraving Systems
★Technical Data of 3D Laser Engraving Systems
Specification | PE-DP-A1/C1/C2/C3 |
Resolution | 800~1200 DPI |
The Galvanometer Type | Digital Galvanometer |
Working wavelength | 532nm |
Scanner lenses | Short focus F-THETA lens 94mm |
Working range | 320mmx400mmx150mm |
Machine size | 880mm x 780mm x 960mm |
Laser | Semiconductor diode |
Semiconductor Life | >20000 hour |
Laser Pulse | 5000HZ |
|
320mm x 400mm x 150mm;support splicing and array carving |
Focal Length | 94mm |
Focus Diameter | 20μm~40μm |
Maximum Engraving Speed | high speed 300,000 |
Repeat Positioning Resolution | 10μm |
Total Power | <500W |
Machine Weight | 100kg |
Cooling Mode | Air Cooling |
Working Condition | Clean,no corrosion,no source,temperature:10-35°C,humidity:<85% |
Power Requirements | 100V-120V / 200v - 240V 50Hz/60Hz |
★ Advantages
1. High quality products and low prices,
2 flexible, non-traceable payment terms.
3. Fast delivery
Products are exported to Germany, Norway, Poland, Finland, Spain, Britain, France, Russia, the United States, Brazil, Mexico, Australia, Japan, South Korea, Thailand, Indonesia, Uruguay and other countries.
★ The following picture is the environment of our factory.
★ Packaging and Delivery
1. Good customer service, on time delivery.
2. If you have any questions or problems after receiving the product, please contact us at any time to provide timely service.
3 packaging team and professional logistics agent.
