Product Details:
Payment & Shipping Terms:
|
| Product Name: | Plasma Cutting Machine PE-CUT-A2 Orange | Voltage: | 220/380V±10% |
|---|---|---|---|
| Rated Power: | 1000W | Weight: | 700KG |
| Frequency Of Power: | 50Hz±1% | Relative Humidity: | 95% |
| Certification: | CE / ISO / FDA SGS / TUV | After-sales Service Provided: | Engineers Service Overseas |
| High Light: | plasma cutting equipment,plasma cutting cnc machine |
||
Product Description
Automatic Industrial Desktop cnc plasma cutter PE-CUT-A2 adopts heavy machine tool design , it combined with the high speed cnc plasma cutting and the need for plate processing heavy machine stability. Berefore, this best
plasma cutter has good rigidity and long stability as well as a significant advantage in thick steel and aluminum materials in cutting 1-20 mm. At the same time, the plasma cutters for sale is equipped with automatic height adjustment system, it can improve work efficiency and save costs.
Main Features
1)Advertising CNC Plasma Cutting Machine adopt bench-gantry structure, welding after the vibration aging treatment to eliminate stress, so that in the long-term use of no deformation
2)All mechanical drive system using rolling bearings and precision machining accuracy as 6 GB of precision gears mesh with the rack
3)Planetary reduce drive system, its input and output error of only 16 arc minutes, at the same time, in the horizontal and vertical structure of the gear drive, an increase of automatic clearance compensation device so that it can accurately drive the structure of the implementation of the directives issued by the CNC.
4) Take the initiative to end beam: vertical track for the introduction of automatic clamping device-oriented structure and there is no eccentric clamping structure, relying on automatic detachable power-oriented structure to make it two. In the track combined with the smooth running of the department will not have a wheel clamp tight or lax-phenomenon.
Technical Data
| Model | PE-CUT-A2 | |
| Effective CuttingWidth(㎜) | Track Gauge-1500 | |
| Effective CuttingLength(㎜) | Gauge Length-3000 | |
| Plasma CuttingThickness(mm) | 1-25mm | |
| Cutting Torch LiftingStroke(㎜) | 60mm | |
| Machine RunningSpeed(mm/min) | 50-45000mm/min | |
| Velocity Error(％) | ≤±5％ | |
| Automatic Height AdjustmentAccuracy(MM) | ≤±1.0mm | |
| Weight | 550KG | |
| Vertical Line Accuracy | ±0.2mm/10m | |
| Linear Repetition Accuracy | ±0.4mm/10m | |
| InstallationAccuracy of Rail |
Rail Side Straightness:0.5mm/10000mm The parallel degree between the rail and the horizontal plane of the guide rail:±0.5mm/10000mm |
|
| PositioningPrecision | 0.1㎜ |
A)Equipment positioning accuracy and repeatability: conform to JB/T5102-1999 standard B)Cutting dimension accuracy, section quality: conform to JB/T10045.3-1999 standard |
| Straightness | 0.2㎜ | |
| Roundness | 0.2㎜ | |
| DiagonalDifference | 0.3㎜ | |
| RepeatedPositioningAccuracy | 0.5㎜ | |
| Machine MarkingAccuracy | ≤0.5mm | |
|
Cutting SurfaceQuality(Roughnes) (σ=25) |
RZ(um)=70+1.2a Visual Measurement: roughness12.5 |
|
Sample Show
Packaging & Delivery
1. Prompt deliver at the very day.
2. Sophisticated and professional logistic agent.
3. Well-trained and disciplined packing team.
4. After-sale service: Any questions or problems after receiving the product, please feel free to contact us. Problems would be solved for you immediately.
Competitive Advantages
1. We offer high quality products at competitive price in quick delivery.
2. 100% custom pass guaranteed.
3. Good after-sale service.
4. Flexible and Untraceable payment terms.
5. Our products have been exported to Germany, Norway, Poland, Finland, Spain, UK, France, Russia, USA, Brazil, Mexico, Australia, Japan, Korea, Thailand, Indonesia, Uruguay and many other countries.
