|Product Name:||PE-S50 Wall Printer||Clarity:||HD Enhanced Version|
|Painting Speed:||High, Medium, Low, Three-speed Adjustable||Painting Resolution:||360*720dpi Or 720*720dpi Or 720*1080dpi Or 720*1440dpi|
|Picture Type:||Support JPG, BMP, TIFF, PDF, AI, PSD, CDR And Other Files||Structure:||Vertical|
|Mainboard Configuration:||6-core CPU, 2GB DDR Memory||Storage:||-30℃-60℃(-22℉-140℉)10%-80% Relative Humidity, Non Condensable State|
|Machine Language:||Chinese,English(Customizable)||Actual Print Size:||2100mm (H) X 4500mm (W)|
wall printing machine,
inkjet wall printer
Perfect Laser is specialized in best selling wide application wall printer with high quality and perfect services. Perfect Laser has successfully developed a multi-color large prints for walls online printer. Adopt to aluminum-magnesium alloy assembly body, the chassis is very thin and durable. In the aspects of product performance, the stability has been significantly improved. Higher painting speed, simple operation, free maintenance, no need to move during work, and the large prints for walls is appropriate for large format painting, beautiful picture and a wide range of applications, this machine is vertical wall printer prior choice.
1. The body of vertical wall inkjet mural printer is made of aluminum-magnesium alloy, high precision, the chassis is thin and durable, easy to carry.
2. Fuselage accessories of vertical wall inkjet mural printer are imported CNC equipment manufacturing, together with a professional mold parts manufacturing process to ensure that the machine and accessories better consistency and higher stability.
3. Large Photo size of vertical wall inkjet mural printer: high 2100mm, width is not limited. Construction no need to move the machine halfway, no need to do stitching, large format painted at one go, beautiful picture.
4. With high-precision brushless servo motor control system, vector positioning, no grating, motor without carbon brush, eliminating the need for cleaning, maintenance, wear and tear after the map garbled, need to regularly replace and other issues, painting high precision, maintain.
5. The vertical wall printer adopts HD piezoelectric inkjet technology. Japan imported piezoelectric nozzle, high precision, clear and bright picture, durable.
6. Variable droplet technology with vertical wall printer. Minimum ink droplets 3.5PL, the largest 27PL, indoor painting screen clear and delicate, outdoor painting color bright, fast.
7. This vertical wall printer adopts advanced ink droplet control system and high fault tolerance are feather technology combined. The output quality is more perfect.
8. The ink of vertical wall printer using imported paste, no heating, minus 10 ℃ to zero 60 ℃ in the normal work environment, no ice, continuous ink, colorful, three-dimensional sense of strong, do not fade, can not afford skin, three-dimensional sense of strong Scrub, green.
9. Sprinkler data signal using optical fiber integrated output. Faster, anti-interference ability, high reliability, stable transmission data.
10. Automatic fill system. Construction accidentally interrupted, fill the system can effectively reduce the painting scrap rate.
11. Fuselage reserved UPS, inverter interface (can be installed built-in power supply system, the vertical wall printer power off for about 10 hours).
12. Advanced AC servo control technology to ensure higher precision printing, better stability and longer service life.
13. Integrated head design of the vertical wall inkjet mural printer, separable structure. Effectively avoid the damage caused by handling bumps, all around the nozzle installation board, thus extending the actual life of the nozzle.
14. Simple multi-color ink cartridges ink system, stable and convenient, to support the separation of fast lines, water and electricity separation, with the take with the release.
15. This vertical wall printer adopts United States imported sensor system, dual sensors, up and down two-way sensor, surface tracking, automatic positioning, automatic solution to the wall uneven, wall tilt and other issues, effectively reducing the risk of head damage.
This kind of vertical wall inkjet mural printer is suitable for a variety of special materials: painted inside and outside wall, wall putty, paint the walls, white porcelain, ceramic tile, walls, glass, paper, canvas, wall, colored glaze, shell powder, wall paint color tablets.
|Model||PE-S50 Vertical Wall Printer|
|Ink||Special ink for synthetic pigment wall painting|
|Assembly method||Self steering fastener, pulley, track fastener, quick disassembly and assembly|
|Control mode||Wired handle, wired control|
|Motor technology||DC brushless servo motor, vector positioning technology, five star grating|
|Feeding system||Negative pressure automatic feeding, 340ml pigment library, multi-color one, special color for, with a sealed plug and dust cover|
|Painting speed||High, medium, low, three-speed adjustable|
|Painting resolution||360*720dpi or 720*720dpi or 720*1080dpi or720*1440dpi|
|Picture type||Support JPG, BMP, TIFF, PDF, AI, PSD, CDR and other files (some formats need to be converted)|
|Actual painted size||Height 2100mm, wide width can be extended|
|Power consumption||No-load 20W, general 75W, Max to 250W|
|Noise||Standby <20dBA, drawing <50dBA|
|Operation||-10℃-60℃(14℉-140℉)10%-80% relative humidity, non condensable state|
|Storage||-30℃-60℃(-22℉-140℉)10%-80% relative humidity, non condensable state|
|System platform||Windows XP/Win 7/Win 8/Win 9/Win 10|
|Motherboard configuration||Sextuple-core CPU, 2GBDDR memory, USB2.0/3.0data interface|
|Print mode||Pass||Speed (per square meter per hour)|
|Quick mode||A||10 Plane / hour|
|Production model||B||56Plane / hour|
|Quality model||C||4.5 Plane / hour|
|High precision model||D||3 Plane / hour|
|Equipment appearance||Actual size||Machine package size||Cross track packing size|
|Weight||60kg||Rack packing weight 61kg||Cross track packing weight 56kg|
|Package type||Wooden box|
|Note: the above technical parameters shall be the design parameters. If there is any difference, the actual use efficiency of the equipment shall prevail.|
