High Quality Two Heads Flat Bed Printer UV For Wood Products

High Quality Two Heads Flat Bed Printer UV For Wood Products

High Quality Two Heads Flat Bed Printer UV For Wood Products
High Quality Two Heads Flat Bed Printer UV For Wood Products
High Quality Two Heads Flat Bed Printer UV For Wood Products
Minimum Order Quantity:
1 unit
Price:
Negotiable
Packaging Details:
Sea-Worthy Packing or Air-Worthy Packing
Delivery Time:
3-7 days
Payment Terms:
T/T, L/C, PayPal, Western Union
Supply Ability:
300 Units Per Month
Get Best Price
Contact Now Chat Now
Detail Information
Place of Origin:
China
Brand Name:
Perfect Laser
Certification:
CE / ISO / FDA / SGS / TUV
Model Number:
PE-UV1315
Print Head Type:
Epson DX5 Or DX7
Ink System:
80mm(130mm Optional)
Operation System:
MS Window 98/Me/2000/XP/Win7
Dimensions:
2310mm*2100mm*1200mm
Sustain Weight:
Max 100KG
Curing Lamp:
Germany Osram LED Light
Y Shaft Drive Screw:
Imported Grinding Rod
Filtration And Brand:
Cobetter
High Light:
digital uv printer , epson flatbed printer
Product Description

High Quality Two Heads Flat Bed Printer UV For Wood Products





Application of Flat Bed Printer UV



1. Glass industry: Various patterns can be directly sprayed on the glass surface to replace the manual painting.
2. Renovation decoration industry: printer uv can directly print patterns on the surface of decorative materials such as ceilings and density boards to meet the requirements of individual customization.





Product Introduction of Flat Bed Printer UV



The printer uv format is 1300*1500mm, and it adopts bidirectional. Printing can increase the speed and efficiency of printing UV lamps alternately curing advantages. Theprinter uv's high production efficiency can greatly reduce production costs. Once printer uv was launched, it has attracted the attention of customers at home and abroad.





Product Features of Flat Bed Printer UV



1.Imported well-known brand linear guides: high precision and very quiet, very stable operation, can greatly reduce the noise generated by the machine running, and longer life.
2.Printer uv equipped with a unique collision avoidance system: The purpose is to prevent accidents caused by manual operation errors and to better protect the machine nozzle.
3.The moisturizing cleaning system is installed: The flat bed printer system is independently developed by Perfect Laser, which can avoid ink waste and save costs.





Model Parameters of Flat Bed Printer UV



Model type Printer UV PE-UV1315
NO. of print heads 2
Print head type Epson DX5 or DX7
Printing resolution 2880*1440dpi(32 Pass),1440*1440dpi(16 Pass),1440*720dpi(8 Pass),720*720dpi(4 Pass),720*360dpi(2 Pass)
Lifting function Intelligent ink tank lifting,electronic-automatic/manual operation intelligent induction to inspect and adjust height
Printing speed 2 PASS 16M²/hr
4 PASS 8M²/hr
8 PASS 4M²/hr
12 PASS 3.7M²/hr
16 PASS 2.5M²/hr
File format TIFF(RGB & CMYK),BMP,PDF,EPS,JPEG
Interface High speed USB transmission interface
Print color High precision intelligent double 4 colors/4 colors(CMYK),double 8 colors/8 colors(white ink optional)
Ink system 1000ml*8 colors
Max Printing size 1300mm*1500mm
Max Media thickness 80mm(130mm optional)
Power consumption 50Hz/60Hz,110/220VAC(±10%),1.5KW
Operation system MS Window 98/Me/2000/XP/Win7
Operation condition Temperature 15℃~35℃,Reative humidity 20%~80%
Dimensions 2310mm*2100mm*1200mm
Packing Dimensions 2540mm*2200mm*1295mm
Sustain Weight Max 100KG
Curing lamp Germany Osram LED light
RIP software USA PP PHOTOPRINT
X axle rail brand and model Taiwan HIWIN mute linear guide rail
X shaft belt Japan Fujifilm industrial wire belt
X axis /Y axis servo motor Taiwan Delta
X axis beam Two times tempered high strength steel, high hardness, no deformation
X/Y axis print towline and wire harness Germany IGUS
Y shaft drive screw Imported grinding rod
Ink car lift rail brand Taiwan HIWIN mute linear guide rail
Platform type and accuracy Glass platform
Solvent capacity and liquid level alarm of main ink box 1L capacity, including liquid level alarm
Filtration and brand Cobetter
Negative pressure control mode Double negative color control
Negative pressure meter brand and model Japan Fujifilm
Electrical switch brand Japan Omron
Ink pipe France Saint-Gobain
X/Y/Z axis master control driver X/Y/Z three axis servo drive, delta exclusive research and development
Sprinkler board control National exclusive network card, 3 cable transmission, easy to upgrade
Ink circulation system White ink circulation, white ink mixing to prevent plugging
Frame structure All steel one-piece frame, non welded or locked aluminum frame





Samples Show of Flat Bed Printer UV



High Quality Two Heads Flat Bed Printer UV For Wood Products 0

High Quality Two Heads Flat Bed Printer UV For Wood Products 1





Packaging & Delivery



1. Prompt deliver at the very day.

2. Well-trained and disciplined packing team.

3. After-sale service:. Any questions or problems after receiving the automatic Paging counter Machine, please feel free to contact us. Problems would be solved for you immediately.

4. Sophisticated and professional logistic agent.





Competitive Advantages



1. 100% custom pass guaranteed.

2. Our products have been exported to Germany, Norway, Poland, Finland, Spain, UK, France, Russia, USA, Brazil, Mexico, Australia, Japan, Korea, Thailand, Indonesia, Uruguay and many other countries.

3. Flexible and Untraceable payment terms.

4. Good after-sale service.

5. We offer high quality products at competitive price in quick delivery.
