Application
Suitable industries:billboards, model industry,electronics and electric appliances, decoration industry, toys and gifts, furniture manufacturing, etc.
Available materials: acrylic, double color boards, plastic, wood, ABS, PVC, MDF, PCB, copper, aluminum and various non-ferrous metals.
Specifications
|
Model |
PEM-1325C |
|
Working area |
1300*2500*200mm |
|
Volume |
3200*2020*1250mm |
|
Main axle power rate |
2.2/3/4.5/5.5KW(optional) |
|
Main axle rotating speed |
6000-24000 rpm/min |
|
Max.Working speed |
8000mm/min |
|
Feeding height |
200mm |
|
Engraving tools |
3.175/4/6/12.7mm |
|
Re-positioning Accuracy |
0.02mm |
|
Supported File Format |
DXF,PLT,G code,MMG,U00,NC,ENG |
|
Power |
AC220V(380V)/50HZ (optional:AC110V/60HZ ) |
|
Weight |
1600kg |
Product Features
1.Spindle motor frequency spindle high power water-cooled, water-proof design.
2.To work long hours, which can realize power, breakpoints, and the next processing, convenient and save labor. Adopts the break-point memory method, guarantee processing under the condition of accident (cutting knife), or the next day.
3.High speed machining: high kinetic energy, Y axis double motor drive, curve, straight line speed. Unique save way of multiple work-piece machining zero.
4.The overall body cast iron beds, and secondary tempering precision machining; widen and thicken beams and columns design,can carve 15MM natural marble with one knife.
5.The device with automatic water system and tank design, to ensure that longer use of the tools.
6.The machine uses water-proof design, to ensure the transmission parts and circuit parts are durable and safe.
Sample Show
Packaging & Delivery
1. Prompt deliver at the very day.
2. Sophisticated and professional logistic agent.
3. Well-trained and disciplined packing team.
4. After-sale service:. Any questions or problems after receiving the product, please feel free to contact us. Problems would be solved for you immediately.
Competitive Advantages
1. We offer high quality products at competitive price in quick delivery.
2. 100% custom pass guaranteed.
3. Good after-sale service.
4. Flexible and Untraceable payment terms.
5. Our products have been exported to Germany, Norway, Poland, Finland, Spain, UK, France, Russia, USA, Brazil, Mexico, Australia, Japan, Korea, Thailand, Indonesia, Uruguay and many other countries.
